TRANSMISSION SPECIFICATIONS

 Frequence [MHz]

 1

 4

 8

 10

 16

 20

 25

 31

 63

 100

 155

 200

 250

 Attenuance (max)

 2

 3.7

 5.5

 5.9

 7.5

 8.4

 9.5

 10.6

 15.3

 19.8

 25.1

 28.9

 32.8

 NEXT (min)

 74.3

 65.2

 60.7

 59.3

 56.2

 54.7

 53.3

 51.8

 47.3

 44.3

 41.4

 39.7

 38.3

 ACR (min)

 42.2

 61.4

 55.4

 53.3

 48.6

 46.3

 43.8

 41.2

 31.9

 24.5

 16.2

 10.8

 5.4

 PS-NEXT (min)

 42.3

 63.2

 58.7

 57.3

 54.2

 52.7

 51.3

 49.8

 45.3

 42.3

 39.4

 37.7

 36.3

 RETURN LOSS (min)

 20

 23

 24.5

 25

 25

 25

 24.3

 23.6

 21.5

 20.1

 19

 18

 17.3

 GENERAL DATA

 Cable

 O.D.

 3.50 x 7.40 mm

 Standard reels

 305 m

 Weight

 4.29 Kg/100 m

 Jacket

 Material

 Reticulated Elastomeric Mixture

 Nom. Thick.

 1.50 mm

 Conductor

 Qty

 4 x 2

 Strand

 1 x 0.53 mm

 Area/AWG

 0.22 mm2/23

 Material

 Annealed solid bare copper polyolefine insulated
