ELECTRICAL DATA

 D.C.R. at 20°C

 ≤ 78 ohm/km

 ≤ 20 ohm/km

  Capacitance

 70 pF/m

 250 pF/m

 Nominal Impedance 1 KHz

 600 ohm/100 m

 Attenuance 1 KHz

 0.50 db/100 m

 Inductance

 < 58 μH/100 m

 Vel. of Prop.

 -

 GENERAL DATA

Cable

 7.00 mm

 100 m

 4.90 Kg/100 m

 Operating temperature

 -5°C/+70°C

 Jacket

 Material

 PVC/Double jacket

 Nom. Thick.

 2.30 mm (Total)

 Shield (double)

 Material

 First and second shield: Bare copper,

 Spiral shield plus 24 AWG tinned copper drain wire

 Coverage

 First: 95% - Second: 95%

 Conductor

 Qty

 2

 Strand

 30 x 0.10 mm

 Area/AWG

 0.22 mm2/24

 Insul. O.D.

 1.10 mm

 Material

 Bare copper polyethylene insulated
