ELECTRICAL DATA

 D.C.R. at 20°C

 < 143 ohm/km

 < 40 ohm/km

  Capacitance

 70 pF/m

 50 pF/m

 Nominal Impedance 1 KHz

 100 pF/m

 Attenuance 1 KHz

 110 ohm/100 m

 Inductance

 7 - 10 db/100 m

 Vel. of Prop.

 80%

 GENERAL DATA

 2

 4

 8

 12

Cable

 8.80 mm

 10.30 mm

 12.90 mm

 15.40 mm

 500 m

 8.50

 12.00

 18.00

 25.00

 Operating temperature

 -20°C/+70°C

 Jacket

 Material

 PVC/Double jacket

 Nom. Thick.

 1.20 mm

 1.30 mm

 Shield (double)

 Material

 Aluminium - Mylar foil,
 Shield plus tinned copper drain wire

 Coverage

 100%

 Conductor

 Qty

 2 x 2

 4 x 2

 8 x 2

 12 x 2

 Strand

 7 x 0.16 mm

 Area/AWG

 0.14 mm2/26

 Insul. O.D.

 1.20 mm

 Material

 Annealed tinned copper cellular polyolefine insulated
