ELECTRICAL DATA

CVS LK Code

 D.C.R. at 20°C

 Conductor

< 11.50 ohm/km

 Shield

 First

 < 4.50 ohm/km

 Second

 Capacitance

 55 pF/m

 Nominal Impedance

 75 ohm

 Attenuance db/100 m - MHz

0.6 at 1 / 1.4 at 5 / 2.0 at 10 / 2.8 at 20/ 4.0 at 40 / 4.6 at 50 / 5.0 at 60 / 6.5 at 100

 Vel. of Prop.

 80%

 Inductance

 GENERAL DATA

 Cable

 O.D.

 Standard reels

 1.000 m

 Weight

 Operating temperature

-20° C/+70° C

 Jacket

 Material

PVC TM2

 Nom. Thick.

 Shield

 Material

 Coverage

 Conductor

 Qty

 Strand

 Area/AWG

 Dielectric O.D.

 Material
