TECHNICAL DATA

 Optical data

 < 0.40 dB/Km at 1300 nm

 < 0.25 dB/Km at 1550 nm

 Electrical data
at 20° C

 ≤ 33.0 ohm/Km (20 AWG)

 ≤ 91.0 ohm/Km (24 AWG)

 ≥ 500 Mohm * Km

 1000 Vdc per 1 min

 GENERAL DATA

 Cable

 9.00 +/- 0.30 mm

 [-20°C +80°C]

 [-30°C +80°C]

 7.5 * O.D.

 10 * O.D.

 120 Kg/Km

 20 N/ mm²

 > 700 N

 Jacket

 LSZH PUR

 Black

 Fleece tape

 Tinned copper braid

 2 x OPTICAL FIBER

 4 x 0.60 mm²

 2 x 0.22 mm²

 OF single-mode (9/125)

 Tinned copper

 Tinned copper

 According to ITU-T G652

 Wire AWG 20/19

 Wire AWG 24/7

 Polyammide

 Polyolefin

 Polyolefin

 Blue, yellow

 2 black, 2 white

 Red, grey

 Diameter

 0.90 mm

 1.50 mm

 1.10 mm
