ELECTRICAL DATA

 D.C.R. at 20°C

 37.50 ohm/km

 17 ohm/km

 Capacitance at 20°C

 100 pF/m

 Nominal Impedance

 50 ohm

 Attenuance

 2.50 db/100 m

 9.70 db/100 m

 13.90 db/100 m

 20.40 db/100 m

 Vel. of Prop.

 66%

 GENERAL DATA

 Cable

 5.00 mm

 1000 m

 3.70 Kg/100 m

 -20°C/+70°C

 Jacket

 PVC

 0.75 mm
