ELECTRICAL DATA

Description

 D.R.C.v

 Conductor

Data: 80 ohm/km - Power: 10 ohm/km

 Shield

 Capacitance 1 Khz

 CDR/CDR

33 pF/m

 CDR/SCR

 Nom. Impedance

110 ohm

 Attenuance

256 KHz

2 db/100 m

 Vel. of Prop.

78%

 Inductance

 GENERAL DATA

 Cable

 O.D.

7.80 mm

 Standard reels

200 m

 Weight

11.50 Kg/100 m

 Operating temperature

 -20°C/+70°C

 Jacket

 Material

PVC flame resistant

 Nom. Thick.

0.70 mm

 Shield

 Material

First: Aluminium - Mylar foil

 Coverage

100%

 Conductor

 Qty

Data: 1 - Power: 2

 Strand

Data: 7 x 0.20 - Power: 43 x 0.25 mm

 Area/AWG

Data: 0.22 mm2/24
Power: 2 mm2/14

 Insul. O.D.

Data: 1.60 mm - Power: 2.70 mm

 Material

Data: Tinned copper P.E. insulated
Power: Tinned copper PVC insulated
