ELECTRICAL DATA

 D.C.R. at 20°C

 85 ohm/km

 40 ohm/km

  Capacitance

 100 pF/m

 180 pF/m

 Nominal Impedance 1 KHz

 530 ohm/100 m

 Attenuance 1 KHz

 0.20 db/100 m

 Inductance

 70 μH/100 m

 GENERAL DATA

 2

 4

 8

 12

 16

Cable

 8.0 mm

 9.6 mm

 12.8 mm

 14.9 mm

 16.9 mm

 500 m

 200 m

 10.30

 15.40

 27.00

 36.80

 46.30

 Operating temperature

 -20°C/+70°C

 Jacket

 Material

 PVC

 Nom. Thick.

 2.50 mm

 1.50 mm

 1.75 mm

 1.85 mm

 Shield (double)

 Material

 Bare copper,
 Spiral shield plus 24 AWG tinned copper drain wire

 Coverage

 > 95%

 Conductor

 Qty

 2 x 2

 4 x 2

 8 x 2

 12 x 2

 16 x 2

 Strand

 28 x 0.10 mm

 Area/AWG

 0.22 mm2/24

 Insul. O.D.

 1.00 mm

 Material

 Annealed bare copper. XLPE insulated
