ELECTRICAL DATA

 D.C.R. at 20°C

 Conductor

 158 ohm/km

 Shield

 14.80 ohm/km

 Capacitance at 20°C

 67 pF/m

 Nominal Impedance

 75 ohm

 Attenuance

 10 MHz

 2.00 db/100 m

 50 MHz

 7.70 db/100 m

 100 MHz

 10.70 db/100 m

 200 MHz

 15.70 db/100 m

 Vel. of Prop.

 66%

 GENERAL DATA

 Cable

 O.D.

 6.20 mm

 Standard reels

 1000 m

 Weight

 5.09 Kg/100 m

 Operating temperature

 -20°C/+70°C

 Jacket

 Material

 PVC

 Nom. Thick.

 1.10 mm

 Shield

 Material

 Coverage

 Conductor

 Qty

 Strand

 Area/AWG

 Dielectric O.D.

 Material
