ELECTRICAL DATA

 D.C.R. at 20°C

 Conductor

61 ohm/km

 Shield

17 ohm/km

 Capacitance

56 pF/m

 Nominal Impedance

75 ohm

 Attenuance db/100 m - MHz

2.30 at 5 / 3.40 at 10 / 4.70 at 20 / 9.0 at 70 / 12.5 at 130 / 17.8 at
270 / 21.5 at 350 / 32.0 at 750 / 35.6 at 1000

 Vel. of Prop.

80%

 GENERAL DATA

 Cable

16.50 mm

200 m

34 Kg/100 m

-20°C/+70°C

 Jacket

PVC

1.60 mm
