ELECTRICAL DATA

 D.C.R. at 20°C

 Conductor

22.5 ohm/km

 Shield

10 ohm/km

 Capacitance

53 pF/m

 Nominal Impedance

75 ohm

 Attenuance db/100 m - MHz

9.0 at 200 / 13.9 at 470 /19.5 at 862 / 21.3 at 1000 /25.0 at 1350 / 27.0 at 1500 / 29.1 at 1750 / 32.8 at 2150 / 35.2 at 2400 / 38.2 at 2750 / 40.5 at 3000

 Vel. of Prop.

84%

 GENERAL DATA

 Cable

7.00 mm

1000 m

6.58 Kg/100 m

-30°C/+70°C

 Jacket

PVC

0.90 mm
