ELECTRICAL DATA

 D.C.R. at 20°C

 Conductor

61.5 ohm/km

 Shield

18 ohm/km

 Capacitance

56 pF/m

 Nominal Impedance

75 ohm

 Attenuance db/100 m - MHz

7.6 at 50 / 15.3 at 230 / 22.3 at 470 / 34.3 at 1000 / 39.7 at 1350 / 42.7 at 1500 / 45.8 at 1750 / 51.6 at 2150 / 55.7 at 2400

 Vel. of Prop.

80%

 GENERAL DATA

 Cable

4.50 mm

500 m

3.00 Kg/100 m

-30°C/+70°C

 Jacket

Low smoke emission PVC

0.65 mm
