ELECTRICAL DATA

 D.C.R. at 20°C

 < 143 ohm/km

 < 40 ohm/km

  Capacitance

 50 pF/m

 100 pF/m

 Nominal Impedance 3 - 8 MHz

 110 ohm/100 m

 Attenuance 3 - 8 MHz

 7 - 10 db/100 m

 Vel. of Prop.

 80%

 GENERAL DATA

16

24

32

 48

Cable

17.40 mm

 22.20 mm

 25.50 mm

 30.80 mm

 500 m

 200 m

32.50

48.20

 61.70

 88.30

 Operating temperature

 -20°C/+70°C

 Jacket

 Material

 PVC

 Nom. Thick.

 1.45 mm

 1.65 mm

 1.75 mm

 1.90 mm

 Shield (double)

 Material

 Aluminium - Mylar foil,
 Shield plus tinned copper drain wire

 Coverage

 100%

 Conductor

 Qty

 16 x 2

 24 x 2

 32 x 2

 48 x 2

 Strand

 7 x 0.16 mm

 Area/AWG

 0.14 mm2/26

 Insul. O.D.

 1.20 mm

 Material

 Annealed tinned copper cellular polyolefine insulated
