ELECTRICAL DATA

 D.C.R. at 20°C

 Audio: < 143 ohm/km - CAT 6: < 80 ohm/km

 Audio: < 93 ohm/km

  Capacitance

 Audio: 50 pF/m - CAT 6: 50 pF/m

 100 pF/m

 Nominal Impedance 1 KHz

 Audio: 110 ohm - CAT 6: 100 ohm

 Attenuance 1 KHz

 Audio: 10 db/100 m @ 10MHz - CAT 6: 30.90 db/100 m@ 250MHz

 Inductance

 Audio: 80% - CAT 6: 66%

 GENERAL DATA

Cable

 23.50 mm

 305 m

 49

 Operating temperature

 -20°C/+70°C

 Jacket

 Material

 PVC

 Nom. Thick.

 2.50 mm

 Shield (double)

 Material

 Aluminium - Polyester tape plus tinned copper drain wire (7 x 0.16 mm)

 Coverage

 100%

 Conductor

 Qty

 Audio: 12 - CAT 6: 2

 Strand

 Audio: 7 x 0.16 mm - CAT 6: 1 x 0.58 mm

 Area/AWG

 Audio: 0.16 mm2/26 - CAT 6: 0.22 mm2/24

 Insul. O.D.

 Audio: 1.20 mm

 Material

 Audio: Annealed tinned copper polyolefine insulated /

 CAT 6: Annealed bare copper polyolefine insulated
