ELECTRICAL DATA

 D.C.R. at 20°C

 75 ohm/km

 20 ohm/km

  Capacitance

 40 pF/m

 85 pF/m

 Nominal Impedance 1 KHz

 110 ohm/100 m

 Attenuance 1 KHz

 3.70 - 5.90 db/100 m

 Inductance

 80%

 GENERAL DATA

Cable

 7.00 mm

 100 m

 5.00 Kg/100 m

 Operating temperature

 -30°C/+60°C

 Jacket

 Material

 PVC

 Nom. Thick.

 1.00 mm

 Shield (double)

 Material

 Double bare copper spiral shield

 Coverage

 First: 90% - Second: 90%

 Conductor

 Qty

 Strand

 30 x 0.10 mm

 Area/AWG

 0.22 mm2/24

 Insul. O.D.

 2.10 mm

 Material

 Bare copper polyethylene insulated
