ELECTRICAL DATA

Description

 D.R.C.v

 Conductor

85 ohm/km

 Shield

 Capacitance 1 Khz

 CDR/CDR

31 pF/m

 CDR/SCR

 Nom. Impedance

120 ohm

 Attenuance

256 KHz

1 db/100 m

 Vel. of Prop.

80%

 Inductance

 GENERAL DATA

 Cable

 O.D.

13.7 mm

 Standard reels

500 m

 Weight

22.20 Kg/100 m

 Operating temperature

 -20°C/+70°C

 Jacket

 Material

PVC

 Nom. Thick.

1.20 mm

 Shield

 Material

First: Aluminium - Polyester foil
Second: Tinned copper braid

 Coverage

First: 100% - Second: 80%

 Conductor

 Qty

8

 Strand

7 x 0.20 mm

 Area/AWG

0.22 mm2/24

 Insul. O.D.

1.50 mm

 Material

Annealed tinned copper
foamed polyolefine insulated
