ELECTRICAL DATA

 D.C.R. at 20°C

 Conductor

244 ohm/km

 Shield

32.4 ohm/km

 Capacitance

54 pF/m

 Nominal Impedance

75 ohm

 Attenuance db/100 m - MHz

1.9 at 1 / 4.3 at 5 / 4.7 at 6 / 5.1 at 7 / 6.1 at 10 / 6.7 at 12 / 16.1 at 67.5 / 16.6 at 71.5 / 18.4 at 88.5 / 19.6 at 100

 Vel. of Prop.

81%

 GENERAL DATA

 Cable

2.54 mm

1000 m

11.30 Kg/100 m

-30°C/+70°C

 Jacket

PVC

0.15 mm
