ELECTRICAL DATA

Description

 D.R.C.v

 Conductor

65 ohm/km

 Shield

 Capacitance 1 Khz

 CDR/CDR

40 pF/m

 CDR/SCR

 Nom. Impedance

110 ohm

 Attenuance

256 KHz

2 db/100 m

 Vel. of Prop.

78%

 Inductance

 GENERAL DATA

 Cable

 O.D.

5.50 mm

 Standard reels

200 m

 Weight

2.90 Kg/100 m

 Operating temperature

 -20°C/+70°C

 Jacket

 Material

PVC flame resistant

 Nom. Thick.

0.85 mm

 Shield

 Material

First: Aluminium - Mylar foil
Second: Tinned copper braid

 Coverage

First: 100% - Second: 75%

 Conductor

 Qty

2

 Strand

7 x 0.20 mm

 Area/AWG

0.22 mm²/24

 Insul. O.D.

 1.60 mm

 Material

Annealed tinned copper foamed
polyethylene insulated
