Directional characteristics

 Supercardioid, lobe-shaped

 Principle of operation

 Pressure gradient, with interference tube

 Cartridge type

 Pre-polarized condenser

 Frequency range

 20 Hz to 20 kHz

 Frequency range, ± 2 dB, at 60 cm

 70 Hz - 18 kHz with typ. 3 dB soft boost at 15 kHz

 Sensitivity, nominal ± 2 dB at 1 kHz

 19 mV/Pa; -34.4 dB re. 1 V/Pa

 Equivalent noise level, A-weighted

 Typ. 14 dB(A) re. 20 μPa (max. 15 dB(A))

 Equivalent noise level, ITU-R BS.468-4

 Typ. 25 dB (max. 26 dB)

 S/N ratio (A-weighted), re.

 1 kHz at 1 Pa (94 dB SPL)

 Typ. 80 dB(A)

 Total Harmonic Distortion (THD)

 < 1 % up to 133 dB SPL peak

 Dynamic range

 Typ. 119 dB

 Max. SPL, peak before clipping

 138 dB

 Filters

 High boost: +4 dB at 8 kHz. Low cut: First order filter, below 120 Hz

 Output impedance

 100 m (328 ft)

 Cable drive capability

 100 m (328 ft)

 Output balance principle

 Signal balanced

 Common Mode Rejection Ratio (CMRR)

 > 40 dB

 Power supply

 48 V Phantom power (± 4 V)

 Current consumption

 4.5 mA

 Connector

 XLR-3M. Pin 1: shield, Pin 2: signal + phase, Pin 3: signal - phase

 Matte black

 68 g (2.4 oz)

 19 mm (0.75 in)

 19 mm (0.75 in)

 212 mm (8.3 in)

 > 1.8 V

 -40 °C to 45 °C (14 °F to 113 °F)
