Directional pattern

 Cardioid

 Principle of operation

 Pressure gradient

 Cartridge type

 Pre-polarized condenser

 Frequency range

 20 Hz - 20 kHz

 Frequency range, ± 2 dB, at 30 cm

 40 Hz - 20 kHz

 Sensitivity, nominal, ± 2 dB at 1 kHz

 10 mV/Pa; -40 dB re. 1 V/Pa

 Equivalent noise level, A-weighted

 Typ. 18 dB(A) re. 20 μPa (max. 20 dB(A))

 Equivalent noise level, ITU-R BS.468-4

 Typ. 25 dB (correct with the attenuator in 0 dB or -20 dB setting)

 S/N ratio (A-weighted), re.

 1 kHz at 1 Pa (94 dB SPL)

 Typ. 76 dB(A)

 Total Harmonic Distortion (THD)

 < 1 % up to 139 dB SPL peak

 Dynamic range

 Typ. 121 dB

 Max. SPL, peak before clipping

 159 dB

 Switchable attenuator

 0 dB / -20 dB

 Output impedance

 < 200 ohm

 Minimum load impedance

 2 kohm

 Cable drive capability

 100 m (328 ft)

 Output balance principle

 Impedance balancing with Active Drive

 Common Mode Rejection Ratio (CMRR)

 > 60 dB

 Power supply (for full specifications)

 48 V Phantom power (± 4 V)

 Current consumption

 2.8 mA

 XLR-3M. Pin 1: shield, Pin 2: signal + phase, Pin 3: - phase

 Matte black

 158 g (5.6 oz)

 19 mm (0.75 in)

 19 mm (0.75 in)

 170 mm (6.7 in)

 > 5 V

 +V at pin 2 for positive sound pressure

 -40 °C to 45 °C (-40 °F to 113 °F)

 Up to 90%

 ± 1 dB

 < 10°
