Directional characteristics | percardioid |
Principle of operation | Pressure gradient |
Cartridge type | Pre-polarized condenser |
Frequency range, ± 2dB, 20cm (7.9in) distance | 80 Hz to 15kHz with 2dB soft boost at 10 to 12kHz; first-order low-cut filter at 80Hz with DAD4099 |
Sensitivity, nominal, ±3dB | 6 mV/Pa; -44.5dB re. 1V/Pa |
Equivalent noise level A-weighted | Typ. 23dB(A) re. 20μPa (max. 26dB(A)) |
S/N ratio, re. 1kHz at 1Pa (94dB SPL) | 71dB |
Total harmonic distortion (THD) | <1% up to 123dB SPL peak; <1% up to 120dB SPL RMS sine |
Dynamic range | 100dB |
Max. SPL, peak before clipping | 142dB |
Output impedance | From MicroDot: 30 to 40 ohm, from DAD4099: 100ohm |
Cable drive capability | 300m (984ft) with DAD4099 |
Output balance principle | Signal balanced with enclosed DAD4099 XLR adapter |
Common Mode Rejection Ratio (CMRR) | > 60dB at 50Hz to 15kHz with DAD4099 XLR adapter |
Power supply | Min. 5V tomax. 50V through DPA adapter for wireless systems; 48V phantom power ±4V with DAD4099 XLR adapter |
Current consumption | 1.5mA; 3.5mA with DAD4099 XLR adapter |
Connector | MicroDot |
Color | Black |
Weight | 33g (1.16oz) |
Microphone length | 45mm (1.8in) |
Cable length | 1.8m (6ft) |
Polarity | Positively increasing sound pressure produces positive going voltage at MicroDot pin (and pin 2 on DAD4099 XLR adapter) |
Operating temperature range | -40°C to 45°C (14°F to 113°F) |
Relative humidity | Up to 90% |
Gooseneck, length | 140mm (5.5 in) |
