Directional characteristics

 Supercardioid

 Principle of operation

 Pressure gradient

 Cartridge type

 Pre-polarized condenser

 Frequency range

 20 Hz to 20 kHz

 Frequency range, ± 2 dB, 20 cm (7.9 in) distance

 80 Hz to 15 kHz with 2 dB soft boost at 10 to 12 kHz

 Sensitivity, nominal ± 3 dB at 1 kHz

 2 mV/Pa; -54 dB re. 1 V/Pa

 Equivalent noise level, A-weighted

 Typ. 28 dB(A) re. 20 μPa (max. 31 dB(A))

 S/N ratio (A-weighted), re.

1 kHz at 1 Pa (94 dB SPL)

 66 dB(A)

 Total Harmonic Distortion (THD)

 <1 % up to 123 dB SPL peak; <1 % up to 120 dB SPL RMS sine

 Dynamic range

 95 dB

 Max. SPL, peak before clipping

 152 dB

 Output impedance

 From MicroDot: 30 to 40 ohm; from DAD4099 or DAD6001: 100 ohm

 Cable drive capability

 Up to 300 m (984 ft) with DAD4099 or DAD6001 XLR adapter

 Output balance principle

 Signal balanced with DAD4099 or DAD6001 XLR adapter

 Common Mode Rejection Ratio (CMRR)

 > 60 dB from 50 Hz to 15 kHz with DAD4099 or DAD6001 XLR adapter

 Power supply (for full performance)

 Min. 5 V to max. 50 V through DPA adapter for wireless systems;

 48 V phantom power +/- 4 V with DAD4099 or DAD6001 XLR adapter

 Current consumption

 Typ. 1.5 mA (microphone). 3.5 mA with DAD4099 or DAD6001 XLR adapter

 Connector

 MicroDot

 Color

 Black

 Capsule diameter

 5.4 mm (0.2 in)

 Microphone length

 45 mm (1.8 in)

 Cable length

 1.8 m (6 ft)

 Polarity

 Positively increasing sound pressure produces positive-going voltage

 at MicroDot pin (and pin 2 on DAD4099 or DAD6001 XLR adapter)

 Temperature range

 -40°C to 45°C (-40°F to 113°F)

 Relative Humidity (RH)

 Up to 90%

 Gooseneck length

 140 mm (5.5 in)
