Directional characteristics

 Supercardioid

 Principle of operation

 Pressure gradient

 Cartridge type

 Pre-polarized condenser

 Frequency range, ± 2 dB, 20 cm (7.9 in) distance

 80 Hz to 15 kHz with 2 dB soft boost at 10 to 12 kHz, Second order

 low-cut filter at 80 Hz with DAD4099

 Sensitivity, nominal, ±3 dB

 2 mV/Pa; -54 dB re. 1 V/Pa

 Equivalent noise level A-weighted

 Typ. 28 dB(A) re. 20 μPa (max. 31 dB(A))

 S/N ratio, re. 1 kHz at 1 Pa (94 dB SPL)

 66 dB

 Total harmonic distortion (THD)

 <1 % up to 123 dB SPL peak; <1 % up to 120 dB SPL RMS sine

 Dynamic range

 95 dB

 Max. SPL, peak before clipping

 152 dB

 Output impedance

 From MicroDot: 30 to 40 ohm, from DAD4099: 100 ohm

 Cable drive capability

 Up to 300 m (984 ft) with DAD4099

 Output balance principle

 Signal balanced with DAD4099-BC XLR adapter

 Common Mode Rejection Ratio (CMRR)

 > 60 dB at 50 Hz to 15 kHz with DAD4099 XLR adapter

 Power supply

 Min. 5 V to max. 50 V through DPA adapter for wireless systems;

 48V phantom power ±4 V with DAD4099 XLR adapter

 Current consumption

 1.5 mA; 3.5 mA with DAD4099 XLR adapter

 Connector

 MicroDot

 Color

 Black

 Weight

 31 g (1.1 oz)

Capsule diameter

 5.4 mm (0.2 in)

 Microphone length

 45 mm (1.8 in)

 Cable length

 1.8 m (6 ft)

 Cable color

 Black

 Polarity

 Positively increasing sound pressure produces positive going voltage

 at MicroDot pin (and pin 2 on DAD4099 XLR adapter)

 Operating temperature range

 -40°C to 45°C (14°F to 113°F)

 Relative humidity

 Up to 90%

 Gooseneck, length

 140 mm (5.5 in)
