Low frequency limit (-10dB)

 40 Hz

 Maximum SPL1

 131 dB

 Component

 1 x 15’’ transducer mounted in a bass-reflex enclosure,
 4’’ coil

 Electrical specifications

 Input stage: balanced, max level of +12 dBu (at 0 dB setting)

 DSP: 24 bit/48 kHz

 (at 0 dB setting) DSP: 24 bit/48 kHz

 H x W x D

 440 x 520 x 520 mm - 17.3 x 20.5 x 20.5 in

 Weight (net)

 36 kg - 79.4 lb.

 Connectors

 2 x XLR in parallel,
 2 x Powercon® 120 or 230 V selectable by switch

 Material

 18, 24 and 30 mm Baltic birch plywood

 Finish

 dark grey brown Pantone® 426C
 pure white RAL® 9010

 polyester powder-coated steel grill,

 cloth

 integrated pole mount socket,

 optional ETR15P bracket
