w frequency limit (-10dB) | 32 Hz ([SB18_100] preset) |
Maximum SPL1 | 136 dB ([SB18_100] preset) |
RMS handling capability | 700 W |
Components | LF: 1 x 18’’ weather-resistant, (4’’ coil, aluminium die-cast basket, vented magnet design) Nominal impedance: 8 ohms |
Rigging2 | Steel, certified for: 16 SB18 (BGV-C1 compliant) |
W x H x D | 750 x 540 x 707 mm - 29.5 x 21.3 x 27.8 in |
Weight (net) | 52 kg - 114.5 lbs |
Connectors | 2 x 4-point Speakon® |
Material | baltic birch plywood |
Finish | dark grey brown Pantone® 426C |
Front | polyester powder-coated steel grill, airnet® acoustically neutral fabric |
Rigging | pole-mount socket, integrated rigging for flying and stacking (steel with dual coating zinc and polyester powder) |
