Directional characteristics | Omnidirectional |
Principle of operation | Pressure |
Cartridge type | Pre-polarized condenser element with vertical diaphragm |
Frequency range, ± 2 dB | Soft boost grid: 20 Hz - 20 kHz, 3 dB soft boost at 8 - 20 kHz, High boost grid: 20 Hz - 20 kHz ±2 dB, 10 dB boost at 12 kHz |
Sensitivity, nominal, ±3 dB | 20 mV/Pa; -34 dB re. 1 V/Pa |
Equivalent noise level A-weighted | Typ. 23 dB(A) re. 20 μPa (max. 26 dB(A)) |
Equiv. noise level ITU-R BS.468-4 | Typ. 35 dB (max. 38 dB) |
S/N ratio, re. 1 kHz at 1 Pa (94 dB SPL) | 71 dB(A |
Total harmonic distortion (THD) | <1% THD up to 123 dB SPL peak |
Dynamic range | Typ. 100 dB |
Max. SPL, peak before clipping | 134 dB |
Output impedance | 30 - 40 Ohm |
Cable drive capability | Up to 300 m (984 ft) |
Power supply | For wireless systems: Min. 5 V ? max. 50 V through DPA adapter; with DAD6001: 48 V phantom power ±4 V. |
Connector | MicroDot |
Weight | 7.5 g (0.26 oz) incl. cable and MicroDot connector |
Microphone length | 12.7 mm (0.5 in) |
Cable length | 3 m (9.4 ft) |
