Acoustic way / Mode Transducer (Ø coil) | 2 way / mono amp 1x5" (1,4") 1 x dome tweeter (0,6") |
Bandwidth @ -3dB Directivity @ -6dB | 65Hz – 19kHz* 110° conical |
Nominal Impedance Power AES Recommanded amplification | 16 Ohm 100 W 100 à 200 W |
Efficiency dB SPL @1W/1m Continuous dB SPL level @1m dB SPL max level @1m | 92 115 121 |
Dimensions (H, W, D) Weight | 260 x 180 x 180 mm 5 kg |
