Acoustic way  / Mode
Transducer (Ø coil)

 2 way / bi amp
 1x15" (3") **
 1 x HF 1,4" (3")

 Bandwidth @ -3dB
Directivity @ -6dB

 50Hz – 20kHz*
 85° conical

 Nominal Impedance
Power AES
Recommanded amplification

 8 Ohm
 lo : 800W                  hi : 125W

 Efficiency dB SPL @1W/1m
Continuous dB SPL level @1m
dB SPL max level @1m

 lo : 100                     hi : 110
 132
 136

 Dimensions (H, W, D)
Weight

 460 x 730 x 367 mm
 29 kg

 ETSMX15

 Lyre bracket for SMX15 in fixed installation

​

 FCSMX15

 Flight Case for 2 x SMX15

​

 Options

 Custom colours and weatherproofing

​
