Audio data

Power

8x200W / 8Ω, 8x300W / 4Ω

Bridged power

4x600W / 8Ω

Input impedance

10kΩ balanced, 20kΩ balanced

Harmonic distorsion

<0.1% from 0,1 W to full power (typically <0,05%)

Electrical data

Mains

90-260 V ±10%, 50-60 Hz

Input connectors

4 x Phoenix MC 1.5/12-ST-3.81

Output connectors

4 x Phoenix DFK-PC 4/8-G-7.62

Mechanical data

Dimensions (WxPxH)

483mm x 88mm x 315mm

Net / shipping weight

9kg / 10.5kg
