Audio data
- Inputs : 8x sym. analog inputs, with switchable mic / line level & phantom power
- Outputs : 8x sym. analog outputs
- Input/output levels : sym. 8Vrms (+20 dBu)
- Dynamic range : 114dB
- Sample frequency : 48 to 192kHz
- Control : Application based control through : driverless USB 2.0, Ethernet
Electrical data
- Mains : 24 VDC power supply
- Power consumption : < 20W / < 2A
- Input connectors : Euroblock 3-pins
- Output connectors : Euroblock 12-pins
Mechanical data
- Dimensions (WxPxH) : 44mm x 480mm x 251mm, 19"-1U
- Net / shipping weight : 3.5kg / 4.3kg
