Usable bandwidth (-10dB)

 50 Hz - 20 kHz ([ARCS II] preset)

 Nominal directivity (-6dB)

 Horizontal: 22.5° symmetrical x N elements

 Vertical: 60° asymmetric (-20°/+40°)

​

 Maximum SPL*

 140 dB ([ARCS II] preset)

 * Peak level measured at 1m under free field conditions using 10 dB crest factor pink noise with specified preset

    and corresponding EQ settings.

​

 RMS power handling capacity

 LF: 600 W

 HF: 100 W

​

 Components

 LF: 1 x 15" neodymium weather-resistant with 4’’ coil

 HF: 1 x 3" neodymium diaphragm compression driver

 Nominal impedance: LF = 8 ohms, HF = 8 ohms

​

 Rigging*

 LIFTBAR certified for 6 ARCS II in a horizontal array

 ARCBUMP certified for 4 ARCS II in a vertical array

  *Mechanical data and limits for installation are specified in SOUNDVISION software which is designed

   to help with L-ACOUSTICS® product implementation.

​

 Physical data

 W/w x H x D: 439/190 x 820 x 652 mm

 17.3/7.5 x 32.3 x 25.7 in

 Weight (net): 50 kg / 110 lbs

 Connectors: 2 x 4-pin SpeakON®

 Cabinet: Baltic birch plywood

 Finish: Grey brown, RAL 8019®

 Front: polyester powder-coated steel grill Airnet® acoustically neutral fabric

 Rigging elements: steel with dual coating (zinc and polyester powder)

​

 Drawings
