Directional characteristics

 Omnidirectional

 Principle of operat

 Pressure

 Cartridge type

 Pre-polarized condenser element with vertical diaphragm

 Frequency range, ± 2 dB

 Soft boost grid: 50 Hz - 20 kHz, 3 dB soft boost at 8 - 20 kHz,

 low-cut -10 dB at 20 Hz.
 High boost grid: 50 Hz - 20 kHz, 10 dB boost at 12 kHz,

 low-cut -10 dB at 20 Hz.

 Sensitivity, nominal, ±3 dB at 1 kHz

 1 mV/Pa; -60 dB re. 1 V/Pa

 Equivalent noise level, A-weighted

 Typ. 33 dB(A) re. 20 μPa (max. 37 dB(A))

 Equiv. noise level ITU-R BS.468-4

 Typ. 45 dB (max. 49 dB)

 S/N ratio, re. 1 kHz at 1 Pa (94 dB SPL)

 61 dB(A)

 Total harmonic distortion (THD)

 < 1 % THD up to 123 dB SPL peak; < 1 % THD up to 120 dB SPL RMS sine

 Dynamic range

 Typ. 90 dB

 Max. SPL, peak before clipping

 154 dB

 Output impedance

 30 - 40 ohm

 Cable drive capability

 Up to 300 m (984 ft)

 Power supply

 For wireless systems: Min. 3 V ? max. 50 V through DPA adapter.
 With DAD6001-BC/DAD6024/DAD4099: 48 V phantom power ±4 V for full

 performance.

 Connector

 MicroDot

 Color

 Black, brown or beige

 Microphone weight

 14 g (0.5 oz) incl. cable and MicroDot connector

 Microphone diameter

 5.4 mm (0.21 in)

 Cable length

 1.2 m (3.9 ft)

 Cable diameter

 1.6 mm (0.06 in)

 Polarity

 Positively increasing sound pressure produces positive going

 voltage on MicroDot

 Operating temperature range

 -10 to 45°C (14 to 113°F)
