Acoustic way / Mode Transducer (Ø coil) | 3 way / bi amp 2x6,5"ND (1.5")** 1xIsotop15TM ND |
Bandwidth @-3dB Directivity @ -6dB | 65Hz - 19kHz* 105°H x 15°V |
Nominal Impedanc AES Power Recommanded amplification | lo : 16 Ohm mid/hi : 16 Ohm lo : 300W mid/hi : 100W lo : 200 to 600W mid/hi : 60 to 160W |
Efficiency dB SPL @1W/1m Continuous dB SPL level @1m dB SPL max level @1m | lo : 99 mid/hi : 101 120 126 |
Dimensions (H, W, D) Weight | 8.3" x 21.3" x 14.2" (210 x 540 x 360 mm) 36 lb (16,5 kg ) |
