Usable bandwidth (± 10 dB) SPL max @ 1m Nominal directivity (H° x V°) Nominal impedance | 55 Hz - 20 kHz 134 dB SPL (1) 70° x 15° (2) 16 ohm |
Transducers Topology Type of load Way and amplification section | 2 x 6,5'' ND with ventilated driver - 1 x Isotop15 (5''ND / HF 1'') Line Source - Isotop / K-Horn Bass Reflex - Line Source / Isotop / Constant directivity 3 ways, bi-amplified |
AES power (W) Maximum power handling (W) | lo/mid : 300 W (3) mid/hi : 100 W lo/mid : 1200 W (4) mid/hi : 400 W |
Dimensions H,W,D (mm) Weight (kg) Connectors IP | 8,2" x 21,2" x 16,1" (210 x 540 x 410 mm) 36,3 lb (16,5 kg) 2 x Speakon NL4MP (5) 43 |
