Acoustical data
- Max SPL : 91dBSPL @ 5m
- Sensitivity : 71dB/1W @ 5m
- Range ±3dB : 6.5m
- Range ±5dB : 12m
- Angle of audience : 0°-5°
- Frequency bandwidth : (-10dB) 120Hz-18kHz
- Horizontal opening angle : ±100° (1kHz) / ±70° (4kHz)
- Vertical directivity : Wavefront synthesis
Electrical data
- Nominal impedance : 8Ω
- Inputs : 1 x symmetrical analog input (Euroblock)
1 x Dante™ RJ45 input
- Power supply : 90V-250V 50Hz/60Hz
- Amplifier : Class D 300W
- Protection : Thermal fuse
- Equalization : Optimal pre-programmed.
Mechanical data
- Dimensions (WxPxH) : 128mm x 117mm x 800mm
- Net / shipping weight : 7.2kg / 8.0kg
- Environment : IP23
- Colors : white, black
