Acoustical data
- Sensitivity : 89dB/1W @ 1m
- Frequency bandwidth : (-3dB / -10dB) 85Hz – 20kHz / 50Hz – 20kHz
- Horizontal opening angle : ±180° (1kHz) / ±80° (4kHz)
- Directivity index (DI) : 1kHz / 4kHz 1.3 / 4.9
- Woofer : 165mm (6.5 in)
- Tweeter : 25mm (1 in)
- Crossover : 3.5kHz 2nd order
Electrical data
- Continous power : 40W
- Peak power : 120W
- Power taps 70V/100V : 2,5W 5W 10W 20W / 5W 10W 20W 40W
- Nominal impedance : 8Ω
- Connectors : Push spring terminals
Mechanical data
- Visible diameter : 280mm (11.02 in)
- Hole cutout diameter : 248mm (9.76 in)
- Min / Max ceiling thickness : 9mm (0.36 in) / 37 mm (1.45 in)
- Net / shipping weight : 3.5kg / 4.4kg
- Environment : IP23
- Colors : white
