Frequency Response

 - .25 dBV 20 Hz;-,1dBV@ 20 kHz

 THD+noise

 < .02% @ 1 kHz

 Total Gain

 18 dBV

 Input Impedance

 20 kOhms-TRS; 10KOhms-3.5mm

 Maximum Input level

 +16.2 dBV-TRS: +10dbv-3.5mm

 Maximum output level

 +5.8 dBV 16Ohms; 9.2 dBV -3.5Ohms

 Headphone Impedance

 16Ohms minimum to 300 Ohms

 Noise at unity gain

 -85 dBV 30Ohms

 Power requirements

 12 VAX,1Amp;2.1mm barrel connector

 Power consumption

 12 Watts maximum

 Output drive power

 1.96 VAC RMS into 16Ohms=240mW

  2.87 VAC RMS into 30Ohms=274mW

 Short circuit protection

 Internal reset fuse ;unplug power reset in 45sec.

 Dimensions

 6.25”w x 7.8”d x 1.8”h
