Description | Passive 2-way coaxial enclosure, controlled and amplified by LA4X / LA8 |
Usable bandwidth (-10 dB) | 95 Hz – 20 kHz ([5XT] preset) |
Maximum SPL1 | 119 dB ([5XT] preset) |
Nominal directivity | 110° axisymmetric |
Transducers | LF: 1 × 5” weather resistant, bass-reflex |
HF: 1 × 1” compression driver |
Nominal impedance | 16 Ω |
Connectors | IN: 1 × 4-point SpeakON® and screw terminal |
LINK: 1 × 4-point SpeakON® and screw terminal |
Rigging and handling | 1 × 3/8” insert for microphone stand |
2 × M6 inserts for ETR5 U-bracket |
Weight (net) | 3.5 kg / 7.7 lb |
Cabinet | First grade Baltic birch plywood |
Finish | Dark grey brown Pantone® 426C |
Pure white RAL® 9010 |
Custom RAL® code on special order |
IP | IP30 or IP35 under specific conditions2 |
