Description

 Active 2-way coaxial enclosure, controlled and amplified by LA4X / LA8

 Usable bandwidth (-10 dB)

 55 Hz - 20 kHz ([X15] preset)

 Maximum SPL1

 136 dB ([X15] preset)

 Nominal directivity

 Vertical: 60°

 Horizontal: 40°

 Monitoring angle2

 35° without risers

 55° with risers

 Transducers

 LF: 1 × 15" neodymium, bass-reflex, laminar ven

 HF: 1 × 3" neodymium compression driver, ellipsoid waveguide

 Nominal impedance

 LF: 8 Ω

 HF: 8 Ω

 Connectors

 IN: SpeakON®

 LINK: SpeakON®

 Rigging and handling

 2 × handles

 DIN580-compatible M8 threaded insert

 4 × M10 threaded inserts

 2 × 35 mm pole sockets

 Weight (net)

 21 kg / 46.2 lb

 Cabinet

 First grade Baltic birch and beech plywood

 Finish

 Dark grey brown Pantone® 426C

 Custom RAL® code on special order

 IP

 IP43
